Emerson Mass Flow Meter Micro Motion Technology: Which Coriolis Meter to Specify

Quick Answer

Emerson mass flow meter Micro Motion technology sets the accuracy benchmark for Coriolis mass flow measurement. Silver Automation Instruments supplies compatible Coriolis meters with direct mass flow, density, and PT100 temperature output. Send your flow range in kg/h, pipe size in DN, fluid name, pressure, and temperature to get a price quote.

Most engineers know Micro Motion from custody transfer, batch dosing, and marine fuel measurement. The meters measure mass directly. Volume based flow meters drift with temperature and pressure changes. Coriolis meters remove that variable. In a chemical plant in Indonesia, a 10 percent density shift from temperature can hide a mass balance error. That is why operators switch to Coriolis.

Silver Instruments builds Coriolis mass flow meters for DN10 to DN150 lines. The transmitter offers 4-20 mA HART, pulse output, and Modbus RTU. No special signal conditioner is needed. Accuracy is 0.1 percent of rate for liquids and 0.5 percent for gases depending on range. Density accuracy is 0.0005 g/cm3.

Emerson Micro Motion versus a Compatible Coriolis Meter

Emerson mass flow meter Micro Motion technology has a large installed base. Spare parts and service are available. But lead time and price can push small and medium plants out of budget. We see this often in Vietnam, Nigeria, Peru, and Saudi Arabia. A paint manufacturer in Southeast Asia asked us for a DN15 meter for resin and solvent batching. The Silver Instruments quote was about 60 percent lower than a comparable Micro Motion part. Lead time was 7 days instead of 10 weeks. That meter has run for 18 months without calibration drift.

Do not start with brand only. Start with process data. A Coriolis meter quote needs fluid, minimum and maximum flow in kg/h, operating pressure in bar, operating temperature in °C, pipe size in DN, and hazardous area class. For chemical dosing with 50 cP viscosity, a straight tube or bent tube meter can work. For gas measurement at 10 bar, check the density calibration range.

Key Specifications Engineers Check

Material choice matters. 316L stainless steel works for many water and chemical processes. For seawater desalination, we suggest Super Duplex or Hastelloy C22. In practice, most users need 316L unless chloride levels exceed 200 mg per liter. A desalination plant in the Middle East used a DN80 Super Duplex Coriolis meter from Silver Instruments for brine discharge. The meter reports mass flow and density. Operators use density to confirm brine concentration. This is more direct than a magnetic flowmeter plus a separate density sensor.

A good Coriol

Emerson Mass Flow Meter Micro Motion Technology: The Industry Standard for Coriolis Meters

is meter has a turndown of 20 to 1 or better. For batch dosing, zero stability matters. This value is expressed in kg/h. A DN15 meter from Silver Instruments has zero stability around 0.02 kg/h. That matters when you dose 5 kg per batch. Most engineers skip the minimum flow step. Then the meter can work at normal flow but lose accuracy at low turndown.

Marine and Food Industry Scenarios

Fuel consumption monitoring on marine vessels is a common request. A Coriolis meter measures kg/h of heavy fuel oil or marine diesel oil. Operators track specific fuel oil consumption and detect hull fouling. Micro Motion units are often specified on newbuild vessels in Singapore and Turkey. Silver Instruments meters are accepted on retrofit projects where the engine room panel needs Modbus data.

Food and beverage plants batch syrups and edible oils. A dairy in Australia uses a DN25 Coriolis meter to dose liquid sugar into mixing tanks. The meter holds 0.2 percent repeatability at 40 °C. Clean in place cycles run at 90 °C for 30 minutes. No flow tube baking issue was reported.

How to Get a Quote

Send us five data points. Flow range in kg/h. Pipe size in DN. Fluid name and viscosity in cP. Pressure in bar and temperature in °C. Hazardous area requirement. If you do not know viscosity, send product name and concentration. We will match meter size to normal, maximum, and minimum flow. Contact Tel: +86-25-68650347, Whatsapp: +86-25-52155837, WeChat: +86 15365082610. Visit flow-meter.com.au for datasheets and installation guides.

FAQ

Is a Silver Instruments Coriolis meter a direct replacement for Emerson Micro Motion?
Not always a direct drop-in. Process connections and wiring may differ. Send the existing model code or photos. We will check flange size, flow range, and output.

What accuracy can I expect on a DN15 meter for liquid?
Liquid mass flow accuracy is 0.1 percent of rate. Density accuracy is 0.0005 g/cm3. Repeatability is better. Test data comes with each meter.

Do you supply ATEX Zone 1 Coriolis meters?
Yes. Explosion proof transmitters are available for Zone 1 and Zone 2. IECEx documents are available for many models. Tell us the gas group and temperature class.

What is the minimum flow rate a Coriolis meter can measure?
It depends on DN size and zero stability. A DN15 meter can measure down to about 1 kg/h with reduced accuracy. For lower gas flows, a thermal mass flow meter may fit better.

How long does delivery take to Southeast Asia or the Middle East?
Standard models ship in 7 to 10 days. Custom wetted materials or special approvals take 3 to 4 weeks. We ship by air or sea based on your project schedule.
