1. Structure of Positive Displacement Flow Meter
In order to meet the requirements of various media and working conditions for flow measurement in production, various types of positive displacement flow meters have been developed. Among them, the more common types are gear type, scraper type, and rotary piston type. Now they are introduced as follows. Volumetric flowmeter (also known as Obal volumetric flowmeter) The schematic diagram of the elliptical gear flowmeter in Figure 1 shows that the flowmeter works by two elliptical gears meshing with each other. The working process is briefly described as follows: P1 in the figure represents the inlet fluid pressure of the flowmeter; Indicating the outlet fluid pressure, it is evident that the pressure P1 is greater than P2. In Figure 1 (a), although the lower travel mold surface rotor is disassembled and slowly subjected to the pressure difference of the fluid, it does not generate rotational torque, while the upper gear generates rotational torque and rotates under the differential pressure of two examples. Due to the meshing of the two gears, they rotate in the direction of the arrow around O1 and O2 as the axis, and at the same time, gear O1 discharges the fluid in the half moon shaped measuring space to the outlet. In the state of Figure 1 (a), the upper gear is the driving wheel and the lower gear is the driven wheel. In the position of Figure 1 (b), both gears generate rotational torque under the differential pressure of the fluid and rotate in the direction of the arrow under this torque, transitioning to The position shown in Figure 1 (c). At this point, the gear position is the same as Figure 1 (a) On the contrary, the lower gear is the driving wheel and
